Model

200W

300W

400W

500W

600W

Input Data(DC)

Recommended Input Power

240Wp

360Wp

480Wp

600Wp

720Wp

Maximum Input Current

20A

25A

30A

35A

45A

DC Voltage Range

10.8-28V

MPPT Volatge Range

15.5-16.5V

Output Data(AC)

Normal Output Voltage

230V（170~260VAC）/110V(90-140VAC)

Normal Frequency

50Hz/60Hz(Auto control)

Power Factor

>97.5%

Total Harmonic Distortion

<5%

Phase Shift

<1%

120V（90~140VAC）Version Efficiency

Peak Efficiency

>89%

>88%

>86%

>85%

>84%

Stable Efficiency

>88%

>87%

>85%

>84%

>83%

230V（190~260VAC）Version Efficiency

Peak Efficiency

>89%

>90%

>87%

>86%

>85%

Stable Efficiency

>88%

>89%

>86%

>85%

>84%

Stand-by Power

<1W

Mechanical Data

Dimensions(L*H*W）

21 x 16.5 x 5.3CM

Protection

Islanding; Short-circuit; converse connection; Low Voltage;                                       Over Voltage; Over temperature Protection

Ambient Temperature Range

-25℃-65℃

Work Environment Humidity

0%~90%RH non-condensing

Grade of Waterproof

Indoor design

Show

LED Indicator

Cooling

Cooling Fan

Features & Compliance

PV Compatibility

36cells(18V solar panel,Vmp:18V,Voc:21V)

EMC Reference

EN61000-6-3:2007 EN61000-6-1:2007

Grid Disturbance Reference

  EN 50178+EN 62109-1+VDE0126-1-12

Grid Detection Reference

DIN VDE 1026 UL1741

Certificate

CE

Package

Net Weight

1.3KGS/PCS

Gross Weight

2.0KGS/PCS

Inner Box (L x W x H)

30*20.3*11.3CM

Carton(L x W x H)

42*31.5*35.5CM, 6pcs/CTN, 7.8/10.6KGS
